ASTM Standards Galvanized Metal / Iron Sheet Galvanized Steel Sheet Plate Price

  Product Show

Grade	SGSS/SGCD1/SGCD2/SGCD3/SGC340,400,440,490,570/ CS TypeA,B,C/FS TypeA/FS TypeB/DDS TypeA,C/EDDS/DX51D+Z
Thickness	0.50-6 mm
Width	600-1250mm
	(usual size:914mm,1000mm,1200mm,1219mm,1250mm,1220mm)
Coil ID	508mm, 610mm
Color weight	4-6 tons
Packing	Standard seaworthy export packing: waterproof paper+steel trip
	packed+wooden case seaworthy package
Delivery	Within 5-10days
Price	FOB&CNF&CIF price
Application:	Galvanized steel is available in a variety of forms, such as galvanized pipes and galvanized wire. It is used everywhere.
	Galvanized steel frames are used to build houses.
	Car parts are made out of galvanized steel, for example, the body of trucks and buses.
	Galvanized metal has found its way into several household appliances such as washing machines, air conditioning housings, hair dryers, etc.
	It is used in high tension electrical towers, protective gears, highway signs etc.
	It is also used to make wrought iron gates and other items.
	Also used to make metal pails.

Chemical Composition %					Mechanical Properties
Steel Brand	C	SiS	Mn	P	S	Elongation %	Yield Strength Mpa	Tensile Strength Mpa
Q195	0.06-0.12	<=0.30	0.25-0.50	<=0.045	<=0.050	>=33	>=195	315-430
Q215	0.09-0.15	<=0.30	0.25-0.55	<=0.045	<=0.050	>=31	>=215	335-450
Q235	0.14-0.22	<=0.30	0.30-0.65	<=0.045	<=0.050	>=26	>=235	375-500
SPHC	0.01-0.06	<=0.05	0.19-0.50	<=0.03	0.001-0.007	>=46	>=305	>=370

For Chemical Composition & Mechanical Properties of Hot Rolled Steel refer to the table:   Hot Rolled Steel Designations & Grades with Comparisons:

Quality	STANDARD	STEEL GRADE
General structural steel (including chequered steel)	GB/T 700-2006 EN 10025-2004 JIS G3101-2004 ASTM A36-05 ASTM A573-05	Q235 (A/B/C/D); Q275 (A/B/C/D) S235JR (ST37-2), S235JO (ST37-3), S275JR (ST44-2) SS400; SS490 A36 Grade 65; Grade 70
Cold forming steel	GB/T 700-2006 EN 10111-2008 JIS G3131-2005	Q195; Q215 (A/B) DD11 (StW22); DD12 (StW23); DD13 (StW24) SPHC; SPHD; SPHE
High strength low alloy structural steel	GB/T 1591-2008 EN 10028-3-2003 EN 10025-2004 ASTM A572-07 ASTM A588-05	Q345 (A/B/C/D/E); Q390; Q420 P355N S420N Grade 50; Grade 60 Grade A; Grade B
Steel for boiler and other pressure vessels	GB 713-2008 ASTM A537-08 JIS G3115	Q245R (20g/20R); Q345R (16Mng/16MnR) Class 1/2/3 SPV235; SPV315; SPV355
Machine structural steel	GB/T 699-1999 EN 10083-1 JIS G4051-2005 ASTM A29-05 SAE J403-95	20#; 35#; 45# C20E; C35E; C45E S20C; S35C; S45C 1020; 1035; 1045 SAE1020; SAE1035; SAE1045
Steel for ship building	LR; ABS, BV, GL, DNV, CCS	A/B/D

  Galvanized Steel and Galvalume Steel – Zehao Steel Designations & Grades with Comparisons:

Quality	GB/T 2518-2004	JIS G3302  G3321	EN 10326-2004 EN 10327-2004	ASTM A653 / A653M ASTM A792 / A792M
Commercial  Steel	01	SGCC (SGHC) SGCH SGLCC	DX51D+Z/AZ	CS TYPE A/B/C
Forming Steel	02	SGCD1 SGLCD1		FS TYPE A/B
Drawing Steel	03	SGCD2  SGLCD2	DX52D+Z/AZ	DDS TYPE A/C
Deep Drawing Steel	04	SGCD3  SGLCD3	DX53D+Z/AZ
Structural Steel	220/250/280/  320/350	SGC (SGH) 340/400/440  SGL400/440	S220/250/280/  320/350GD  +Z / AZ	SS  Grade  33[230]-80[350]
